Type

Direct Cool

Gross Volume

380 Ltr.

Net Volume

365 Ltr.

Climatic Type (SN, N, ST, T)

N~ST

Rated Operating Voltage and Frequency

220-240V~ and 50Hz

Compressor Input Power (Watt)

V 0401- 130
V 0501- 50.3~166.7
V 0601- 130
V 0701- 130
V 0702- 130
V 0703-130
V 0801-33.78~126.46
V 0802-33.78~126.46
V 0901-33.78~126.46
V 0902-33.78~126.47
V 1001-33.78~126.48

Compressor Type

V 0401- RSCR
V 0501-BLDC
V 0601- RSCR
V 0701- RSCR
V 0702- RSCR
V 0703-RSCR
V 0801-BLDC
V 0802-BLDC
V 0901-BLDC
V 0902-BLDC
V 1001-BLDC

Cooling Effect

Freezer Cabinet Less than -18℃
Refrigerator Cabinet 0℃ to +5℃

Temperature Control (Electronic/ Mechanical)

V 0401- Mechanical
V 0501- Mechanical
V 0601- Mechanical
V 0701- Mechanical
V 0702- Mechanical
V 0703-Mechanical
V 0801-Mechanical
V 0802-Electronic
V 0901-Mechanical
V 0902-Electronic
V 1001-Electronic

Defrosting (Automatic/ Manual)

Manual

Reversible Door

No

Handle (Recessed/ Grip)

Recessed/ Grip

Lock

Yes

Capillary

Copper

Polyurethane foam blowing agent

Cyclopentene
[Eco-friendly (100% CFC &
HCFC Free) Green Technology]

Operating voltage

V 0401/V 0601/V 0701/V 0702/V 0703: Need Voltage  stabilizer capacity is 2100VA
V 0501: Wide Voltage Design (105V-276V)
V 0801:Wide Voltage Design (75V-264V)
V 0901/V 0902/V 1001:Wide Voltage Design (80V-300V)
N.B.: If out of voltage range(75V-264V) then suggested voltage stabilizer capacity is 2100VA.

Shelf (Material/ No.)

Glass/3

Door Basket

4

Interior Lamp

Yes

Vegetable Crisper

Yes/1

Vegetable Crisper Cover

Yes

Egg Tray

Yes/2

Can Storage Dispenser

No

Shelf (Material/ No.)

Wire/2

Drawer

No

Door Basket

2

Interior Lamp

No

Width/mm

650

Depth/mm

650

Height/mm

1860

Width/mm

710

Depth/mm

710

Height/mm

1910

Weight/Kg - Net/Packing

67/ 76 ± 2

Loading Capacity- 40HQ/ 40Ft/ 20Ft

66/ 48/ 24

Star rating (BDS 1850:2012)

5
